Springfox Swagger Extensions für Spring Security

1@Configuration
2public class SecurityConfig extends WebSecurityConfigurerAdapter {
3    @Override
4    protected void configure(HttpSecurity httpSecurity) throws Exception {
5        super.configure(httpSecurity);
6
7        httpSecurity.csrf().disable();
8        httpSecurity.httpBasic();
9
10        httpSecurity.authorizeRequests()
11            .antMatchers(HttpMethod.POST, "/user").hasRole("admin")
12            .antMatchers(HttpMethod.GET, "/user/*").hasAnyRole("admin", "user");
13
14        httpSecurity.authorizeRequests().anyRequest().fullyAuthenticated();
15    }
16}

1@RestController
2public class MyRestController {
3    @RequestMapping(method = RequestMethod.GET, value = "/user/{username}", produces = APPLICATION_JSON_VALUE)
4    @ApiOperation("Get details of a user with the given username")
5    @ApiResponses(value = {
6            @ApiResponse(code = 200, message = "Details about the given user"),
7            @ApiResponse(code = 401, message = "Cannot authenticate"),
8    })
9    public UserDTO getExampleData(@Valid
10                                  @ApiParam("Non-empty username") @PathVariable(name = "username", required = true) String username) {
11        /*
12            Get your user resource somehow and return
13         */
14    }
15    @PostMapping(value = "/user", consumes = MediaType.APPLICATION_JSON_VALUE, produces = MediaType.APPLICATION_JSON_VALUE)
16    @ResponseStatus(HttpStatus.CREATED)
17    @ApiOperation("Create a new user or update an existing user (based on username)")
18    @ApiResponses(value = {
19            @ApiResponse(code = 200, message = "User was successfully updated"),
20            @ApiResponse(code = 201, message = "User was successfully created"),
21            @ApiResponse(code = 401, message = "Cannot authenticate"),
22    })
23    public void createUser(@Valid @RequestBody UserDTO userDTO) {
24        /*
25            Save the user resource somehow
26        */
27    }
28}

1public class HttpMethodResourceAntMatchers {
2    Logger logger = LoggerFactory.getLogger(HttpMethodResourceAntMatchers.class);
3    // list of all defined matchers
4    List matcherList = new ArrayList<>();
5    /**
6     * Applies all existing Matchers to the provided httpSecurity object as .authorizeRequest().antMatchers().hasAnyRole()
7     * @param httpSecurity
8     * @throws Exception
9     */
10    public void configure(org.springframework.security.config.annotation.web.builders.HttpSecurity httpSecurity) throws Exception {
11        for (HttpMethodResourceAntMatcher matcher : this.matcherList) {
12            httpSecurity.authorizeRequests().antMatchers(matcher.getMethod(), matcher.getAntPattern()).hasAnyRole(matcher.getRoles());
13        }
14    }
15    /**
16     * Add a new Matcher with HttpMethod and URL-Path
17     * @param method
18     * @param antPattern
19     * @return
20     */
21    public Role antMatchers(org.springframework.http.HttpMethod method, String antPattern) {
22        // create a new matcher
23        HttpMethodResourceAntMatcher matcher = new HttpMethodResourceAntMatcher(method, antPattern);
24        // add matcher to list of matchers
25        this.matcherList.add(matcher);
26        // return a Role wrapper object, which forces the user to add the role(s) to the matcher
27        Role role = new Role(matcher, this);
28        return role;
29    }
30    /**
31     * Helper class for a builder-like creation pattern
32     */
33    public class Role {
34        HttpMethodResourceAntMatcher matcher;
35        HttpMethodResourceAntMatchers matchers;
36
37        public Role(HttpMethodResourceAntMatcher matcher, HttpMethodResourceAntMatchers matchers) {
38            this.matcher = matcher;
39            this.matchers = matchers;
40        }
41        /**
42         * Define which role has access to the given resource identified by the Ant-Matcher
43         * @param role
44         * @return
45         */
46        public HttpMethodResourceAntMatchers hasRole(String role) {
47            matcher.setRoles(role);
48            return matchers;
49        }
50        /**
51         * Add a list of roles which have access to the given resource identified by the Ant-Matcher
52         * @param roles
53         * @return
54         */
55        public HttpMethodResourceAntMatchers hasAnyRole(String... roles) {
56            matcher.setRoles(roles);
57            return matchers;
58        }
59    }
60}

1@Component
2public class MatchersSecurityConfiguration {
3
4    private HttpMethodResourceAntMatchers matchers;
5
6    /**
7     * Returns all http matchers
8     * @return
9     */
10    public HttpMethodResourceAntMatchers getMatchers() {
11        if (matchers == null) {
12            matchers = new HttpMethodResourceAntMatchers();
13            matchers.antMatchers(HttpMethod.POST, "/user").hasRole("admin")
14                    .antMatchers(HttpMethod.GET, "/user/*").hasAnyRole("admin", "user");
15        }
16        return matchers;
17    }
18}

1@Configuration
2public class SecurityConfig extends WebSecurityConfigurerAdapter {
3
4    @Autowired
5    private MatchersSecurityConfiguration matchersSecurityConfiguration;
6
7    @Override
8    protected void configure(HttpSecurity httpSecurity) throws Exception {
9        super.configure(httpSecurity);
10
11        httpSecurity.csrf().disable();
12        httpSecurity.httpBasic();
13        // add matchers for REST API to httpSecurity
14        this.matchersSecurityConfiguration.getMatchers().configure(httpSecurity);
15
16        httpSecurity.authorizeRequests().anyRequest().fullyAuthenticated();
17    }
18}

1import java.lang.annotation.ElementType;
2import java.lang.annotation.Retention;
3import java.lang.annotation.RetentionPolicy;
4import java.lang.annotation.Target;
5
6@Target({ElementType.METHOD})
7@Retention(RetentionPolicy.RUNTIME)
8public @interface ApiRoleAccessNotes {
9}

1@Component
2@Order(SwaggerPluginSupport.SWAGGER_PLUGIN_ORDER)
3public class OperationNotesResourcesReader implements springfox.documentation.spi.service.OperationBuilderPlugin {
4    private final DescriptionResolver descriptions;
5
6    @Autowired
7    private MatchersSecurityConfiguration matchersSecurityConfiguration;
8
9    final static Logger logger = LoggerFactory.getLogger(OperationNotesResourcesReader.class);
10
11    @Autowired
12    public OperationNotesResourcesReader(DescriptionResolver descriptions) {
13        this.descriptions = descriptions;
14    }
15
16    @Override
17    public void apply(OperationContext context) {
18        try {
19            Optional methodAnnotation = context.findAnnotation(ApiRoleAccessNotes.class);
20            if ( !methodAnnotation.isPresent() || this.matchersSecurityConfiguration == null) {
21                // the REST Resource does not have the @ApiRoleAccessNotes annotation --> ignore
22                return;
23            }
24            String apiRoleAccessNoteText = "Accessible by users having one of the following roles: ";
25            HttpMethodResourceAntMatchers matchers = matchersSecurityConfiguration.getMatchers();
26            // get all configured ant-matchers and try to match with the current REST resource
27            for (HttpMethodResourceAntMatcher matcher : matchers.matcherList) {
28                // get the RequestMapping annotation, which contains the http-method
29                Optional requestMappingOptional = context.findAnnotation(RequestMapping.class);
30                if (matcher.getMethod() == getHttpMethod(requestMappingOptional)) {
31                    AntPathMatcher antPathMatcher = new AntPathMatcher();
32                    String path = context.requestMappingPattern();
33                    if (path == null) {
34                        continue;
35                    }
36                    boolean matches = antPathMatcher.match(matcher.getAntPattern(), path);
37                    if (matches) {
38                        // we found a match for both http-method and URL-path, get the roles
39                        // add the roles to the notes. Use Markdown notation to create a list
40                        apiRoleAccessNoteText = apiRoleAccessNoteText + "\n * " +  String.join("\n * ", matcher.getRoles());
41                    }
42                }
43
44            }
45            // add the note text to the Swagger UI
46            context.operationBuilder().notes(descriptions.resolve(apiRoleAccessNoteText));
47        } catch (Exception e) {
48            logger.error("Error when creating swagger documentation for security roles: " + e);
49        }
50    }
51
52    private HttpMethod getHttpMethod(Optional requestMappingOptional) {
53        if (!requestMappingOptional.isPresent()) return null;
54        if (requestMappingOptional.get().method() == null || requestMappingOptional.get().method()[0] == null)
55            return null;
56        RequestMethod requestMethod = requestMappingOptional.get().method()[0];
57        switch (requestMethod) {
58            case GET:
59                return HttpMethod.GET;
60            case PUT:
61                return HttpMethod.PUT;
62            case POST:
63                return HttpMethod.POST;
64            case DELETE:
65                return HttpMethod.DELETE;
66        }
67        return null;
68    }
69
70    @Override
71    public boolean supports(DocumentationType delimiter) {
72        return SwaggerPluginSupport.pluginDoesApply(delimiter);
73    }
74}

1@RestController
2public class MyRestController {
3    @RequestMapping(method = RequestMethod.GET, value = "/user/{username}", produces = APPLICATION_JSON_VALUE)
4    @ApiOperation("Get details of a user with the given username")
5    @ApiResponses(value = {
6            @ApiResponse(code = 200, message = "Details about the given user"),
7            @ApiResponse(code = 401, message = "Cannot authenticate"),
8    })
9    @ApiRoleAccessNotes
10    public UserDTO getExampleData(@Valid
11                                  @ApiParam("Non-empty username") @PathVariable(name = "username", required = true) String username) {
12        /*
13            Get your user resource somehow and return
14         */
15    }
16
17    @PostMapping(value = "/user", consumes = MediaType.APPLICATION_JSON_VALUE, produces = MediaType.APPLICATION_JSON_VALUE)
18    @ResponseStatus(HttpStatus.CREATED)
19    @ApiOperation("Create a new user or update an existing user (based on username)")
20    @ApiResponses(value = {
21            @ApiResponse(code = 200, message = "User was successfully updated"),
22            @ApiResponse(code = 200, message = "User was successfully created"),
23            @ApiResponse(code = 401, message = "Cannot authenticate"),
24    })
25    @ApiRoleAccessNotes
26    public void createUser(@Valid @RequestBody UserDTO userDTO) {
27        /*
28            Save the user resource somehow
29        */
30    }
31}
