Integration von JavaFX in Swing-Applikationen

1// Initialize FX runtime when the JFXPanel instance is constructed
2private synchronized static void initFx() {
3    // Note that calling PlatformImpl.startup more than once is OK
4    PlatformImpl.startup(() -> {
5        // No need to do anything here
6    });
7}

1public class SwingFXPanel extends JFXPanel {
2
3    private Button testButton;
4    private TextField testTextField;
5    private Label testLabel;
6
7    public SwingFXPanel() {
8        init();
9    }
10
11    private void init() {
12        testButton = new Button("I am a JavaFX Button");
13        testTextField = new TextField();
14        testLabel = new Label("empty");
15        VBox pane = new VBox(testTextField, testButton, testLabel);
16        pane.setAlignment(Pos.CENTER);
17        setScene(new Scene(pane));
18    }
19
20    public Button getTestButton() {
21        return testButton;
22    }
23
24    public TextField getTestTextField() {
25        return testTextField;
26    }
27
28    public Label getTestLabel() {
29        return testLabel;
30    }
31
32}

1public class SwingPanel extends JPanel{
2
3    private JButton testButton;
4    private JTextField testTextField;
5    private JLabel testLabel;
6
7    public SwingPanel() {
8        init();
9    }
10
11    private void init(){
12        setLayout(new BorderLayout());
13        JPanel panel = new JPanel();
14        panel.setLayout(new BoxLayout(panel, BoxLayout.Y_AXIS));
15        testButton = new JButton("I am a Swing Button");
16        testTextField = new JTextField();
17        testLabel = new JLabel("empty");
18        testButton.setAlignmentX(Component.CENTER_ALIGNMENT);
19        testTextField.setAlignmentX(Component.CENTER_ALIGNMENT);
20        testLabel.setAlignmentX(Component.CENTER_ALIGNMENT);
21        Box.Filler filler1 = new Box.Filler(new Dimension(0, 0), new Dimension(0, 1000), new Dimension(0, 32767));
22        Box.Filler filler2 = new Box.Filler(new Dimension(0, 0), new Dimension(0, 1000), new Dimension(0, 32767));
23        panel.add(filler1);
24        panel.add(testTextField);
25        panel.add(testButton);
26        panel.add(testLabel);
27        panel.add(filler2);
28        add(panel, BorderLayout.CENTER);
29    }
30
31    public JButton getTestButton() {
32        return testButton;
33    }
34
35    public JLabel getTestLabel() {
36        return testLabel;
37    }
38
39    public JTextField getTestTextField() {
40        return testTextField;
41    }
42
43}

1public class InteropFrame extends JFrame {
2
3    private JSplitPane centralSplitPane;
4    private SwingPanel swingPanel;
5    private SwingFXPanel swingFXPanel;
6
7    public InteropFrame() {
8        init();
9    }
10
11    private void init() {
12        setTitle("Swing - JavaFX Interoperability");
13        setSize(800, 500);
14        setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
15        setLayout(new BorderLayout());
16        centralSplitPane = new JSplitPane();
17        swingPanel = new SwingPanel();
18        swingFXPanel = new SwingFXPanel();
19        swingPanel.getTestButton().addActionListener((ActionEvent e) -> {
20            Platform.runLater(() -> {
21                swingFXPanel.getTestLabel().setText(swingPanel.getTestTextField().getText());
22            });
23        });
24        swingFXPanel.getTestButton().setOnAction(a -> {
25            swingPanel.getTestLabel().setText(swingFXPanel.getTestTextField().getText());
26        });
27        centralSplitPane.setLeftComponent(swingPanel);
28        centralSplitPane.setRightComponent(swingFXPanel);
29        add(centralSplitPane, BorderLayout.CENTER);
30    }
31
32}

1<VBox alignment="CENTER" xmlns="http://javafx.com/javafx/8" xmlns:fx="http://javafx.com/fxml/1">
2    <children>
3        <TextField fx:id="testTextField" />
4        <Button fx:id="testButton" mnemonicParsing="false" text="I am a JavaFX Button" />
5        <Label fx:id="testLabel" text="empty" />
6    </children>
7</VBox>

1public class SwingFXMLPanel extends JFXPanel {
2
3    @FXML
4    private Button testButton;
5    @FXML
6    private TextField testTextField;
7    @FXML
8    private Label testLabel;
9    private VBox pane;
10
11    public SwingFXMLPanel() {
12        init();
13    }
14
15    private void init() {
16        FXMLLoader loader = new FXMLLoader(getClass().getResource("demo.fxml"));
17        loader.setController(this);
18        try {
19            loader.load();
20        } catch (IOException ex) {
21            Logger.getLogger(SwingFXMLPanel.class.getName()).log(Level.SEVERE, null, ex);
22        }
23        pane = loader.getRoot();
24        Platform.runLater(this::createScene);
25    }
26
27    public void createScene() {
28        Scene scene = new Scene(pane);
29        setScene(scene);
30    }
31
32    public Button getTestButton() {
33        return testButton;
34    }
35
36    public TextField getTestTextField() {
37        return testTextField;
38    }
39
40    public Label getTestLabel() {
41        return testLabel;
42    }
43}
